How to Install Line Post Insulators ("brackets") on Wood Posts
Once your end posts are drilled and hardware is installed, it’s time to move down the fence line.
In Episode 6 of the Cameo™ Fence Skill Builder Series, Clayton demonstrates how to install Line Post Insulators on wood posts - PRO-TIP: they can be used on wood, steel, or iPosts.
This is one of the fastest steps in the installation process — when done correctly.
Why Line Post Insulators ("brackets") Matter
-
Hold your Cameo strands with consistent spacing
-
Maintain alignment along the entire fence run
-
Keep tension clean and uniform
-
Improve overall fence appearance
If insulators are uneven, your Cameo lines will not run smoothly. Precision creates professional results.
Before You Start
All posts should already be:
-
Set at 52 inches
-
Flowing naturally with the terrain
-
Properly spaced (typically 12 feet apart)
The 52-inch height is critical — it sets up your posts to use the exact measurements we'll list below for a 6-line Cameo fence system. Also, it allows the Cameo Story Pole to work without adjustment.
Tools and Materials Required
This step is refreshingly simple.
You only need:
-
Drill
-
1/4-inch nut driver
-
Cameo Story Pole
-
Line Post Insulators ("brackets")
-
Screws
Step 1: Center the Story Pole
Place the Cameo Story Pole directly on top of the wood post.
Make sure it is:
-
Fully seated
-
Centered properly
-
Aligned straight with the fence run
The Cameo Story Pole automatically aligns the insulators for a 6-strand Cameo Fence System.
No tape measure needed.
No recalculating heights.
Step 2: Insert the First Insulator
With the Story Pole in place:
-
Insert a Line Post Insulator into the designated slot.
-
Grab two screws.
-
Install the BOTTOM Insulator FIRST.
Why Start From the Bottom?
-
It ensures you’re centered from the base upward.
-
It prevents cumulative alignment errors.
Consistency builds upward.
Step 3: Work Your Way Up
Continue installing Cameo Line Post Insulators one-by-one as you move up the post.
Each bracket:
-
Slides into the story pole guide
-
Receives two screws
-
Locks into position cleanly
Because the story pole handles spacing, installation is:
-
Fast
-
Efficient
-
Nearly mistake-proof
Step 4: Remove the Story Pole
Once all insulators are installed:
-
Remove the story pole.
-
Inspect alignment.
-
Confirm screws are snug (not over-tightened).
Your line post is now ready to receive Cameo and Cameo Pulse lines.
Why This System Works
The combination of:
-
52-inch post height
-
Pre-marked story pole
-
Bottom-up insulator installation
Creates a system that:
-
Eliminates measurement errors
-
Expedites installation
-
Maintains uniform wire spacing
-
Produces professional results
Cameo Fence Systems installed in this manner create a safe and aesthetically pleasing fence line that runs along your property smoothly.
***If you don't have the Cameo Story Pole, mark the following measurements on a 52" post: 48", 40", 32", 24", 16", & 8".
Common Mistakes to Avoid
❌ Not centering the Story Pole
❌ Starting at the top instead of the bottom
❌ Over-driving screws
❌ Forgetting to ensure posts follow terrain
❌ Installing Insulators without the Story Pole
The Cameo Story Pole truly makes this system efficient!
What’s Next?
Now that:
-
End posts are drilled and hardware installed
-
Line Post Insulators are installed
You’re ready to start pulling and tensioning your Cameo™ strands.
Each episode builds on the last — turning what seems complex into a streamlined, repeatable installation process.
Frequently Asked Questions
What height should wood posts be set for Cameo fencing?
Posts should be set at 52 inches to align perfectly with the Cameo Story Pole and ensure consistent insulator spacing.
What tool is needed to install Line Post Insulators?
A drill with a 1/4-inch nut driver is all that’s required.
Why use a Cameo Story Pole for Line Post Insulator installation?
The Story Pole ensures consistent spacing between lines, eliminates measuring errors, and expedites installation.
How many screws are used per Line Post Insulator?
Each Insulator is secured with two screws.
Should I start installing insulators from the top or bottom?
Start from the bottom and work upward. This helps maintain consistent alignment and centering.
Do I need to measure each bracket height?
No. The story pole handles all spacing automatically.
If I don't have a Story Pole, what are the measurements at which I should place my Line Post Insulators?
If you don't have the Cameo Story Pole, mark the following measurements on a 52" post: 48", 40", 32", 24", 16", & 8".
